Ref. 3832 Bridge sawing machine NC

Price On demand
Creation date October 11, 2016
Expiration date December 31, 2017
Advertiser FseSrl FseSrl http://www.fsesrl.com/
Contact advertiser

Description

Year: 1999
Brand: PEDRINI
Model: M912CN

Max allowable disc diameter 400 mm (optional 900 mm)
Disc inclination 0°÷ 90°
Useful cutting lenght with disc diam. 625 mm and 170 mm slab thickness (X axis)3500 mm
Crosswise bridge stroke (axis Y) 3500 mm
Disc raising-lowering stroke (axis Z) 370 mm
Inclined disc raising-lowering stroke (axis Z2) 180 mm
Disc motor power 22 kW
Rotating bench with 5000 kg maximum load capacity - motorized with pneumatic locking system (axis B)Rotating bench dimensions: 3500x1800 mm
Installed electric power 28 kW
